8mp Usb Camera Module With LED Fill Light

Brand Name : Sinoseen

Model Number : SNS-DZ1041-V1.0

Certification : RoHS

Place of Origin : Shenzhen,China

MOQ : 5

Price : negotiable

Payment Terms : T/T

Supply Ability : 500000 pieces/month

Delivery Time : 2-3weeks

Packaging Details : Tray+Anti-static bag in carton box

Type : 8mp camera module

Sensor : 1/3.2'' IMX179

Resolution : 3264(H) x 2448(V)

Dimensions : (customizable)

Lens FOV : 100°(optional)

Focus Type : Fixed focus

Interface : USB3.0

Feature : 4K

Contact Now

oem hd imx179 8mp usb camera module with LED fill light for industrial endoscopy



* 8 million pixels, using SONY IMX179 CMOS image sensor

* High quality image, high sensitivity, low power consumption, low current

* High resolution, max resolution 3264X2448

*With LED fill light, you can press the button to take pictures and change the imaging direction

*For industrial inspection and industrial endoscopy Highest Frame Rate - 30 fps at 1024*768 resolution

*UVC for Win XPWin7Win8AndroidLinuxMac OS

*Compliant with UVC standard, no driver, plug and play, support Linux, Android, Mac and Windows, OTG



Specification

Model No

SNS-DZ1041-V1.0

Sensor

1/3.2’’ IMX179

Pixel

8 Mega Pixel

Most effective pixels

3264(H) x 2448(V)

Pixel Size

1.4µm x 1.4µm

Compression format

MJPG / YUY2

Resolution

see above

Frame rate

see above

Shutter Type

Electronic rolling shutter

Focus type

Fixed focus

S/N ratio

36dB

Dynamic range

60dB

Interface type

USB2.0

Adjustable parameter

Brightness/Contrast/Color saturation/Hue/Definition/
Gamma/White balance/Exposure

Lens

Focal length: 3.6mm



Lens Size: 1/3 inch



FOV: 95° (Optional)



Thread Size: M12*P0.5

Audio frequency

Support

microphone

Built-in

Power supply

USB BUS POWER

Power consumption

DC 5V, 200mA

Main chip

DSP/SENSOR/FLASH

Auto Exposure Control (AEC)

Support

Auto White Balance (AEB)

Support

Auto Gain Control (AGC)

Not Supported

Dimension

90MM x 15MM (customizable)

Storage temperature

-20°C to 70°C

Operating temperature

0°C to 60°C

USB cable length

Default


Support OS

WinXP/Vista/Win7/Win8/Win10
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Android 4.0 or above with UVC
