Auto Fixed Focus 16MP USB Camera Module Global Shutter For Face Recognition

Brand Name : Sinoseen

Model Number : SNS-USB

Certification : RoHS

Place of Origin : Shenzhen,China

MOQ : 3

Price : negotiable

Payment Terms : T/T

Supply Ability : 500000 pieces/month

Delivery Time : 2-3weeks

Packaging Details : Tray+Anti-static bag in carton box

Type : USB camera module

Sensor : Omnivision/SONY/ON Semiconductor/GalaxyCore...

Resolution : 0.3MP 1MP 2MP 3MP 4MP 5MP 8MP 13MP 16MP

Dimensions : 32x32mm/38x38mm/customizable

Lens FOV : 20~200degrees

Focus Type : Fixed focus/Auto focus

Interface : USB2.0/USB3.0

Feature : WDR/HDR/Global Shutter/Starvis/HRF....

Contact Now

Auto Fixed Focus 16MP USB Camera Module Global Shutter For Face Recognition

Sinoseen factory price OEM Auto/Fixed focus USB2.0/3.0 camera module customization as per your request



We can customize various types of USB camera modules. If you know the sensor very well, you can give the specified sensor. Or you can simply describe your specific application scenarios and the features you may need, and we will recommend the most suitable sensor according to your actual needs.

You can customize the size of the PCB according to your actual needs. Our engineers will evaluate whether it can fit all the required components and give appropriate suggestions.

As for the lens, you can choose autofocus or fixed focus according to your actual needs, and the degrees of the FOV can also be chosen at will. You can also decide whether to add LEDs or microphones to your camera module to achieve other functions.

All you need to do is to cooperate with our engineers to determine the details of some requirements, we will draw a drawing for you to confirm before making the samples. Once the drawing is confirmed, the rest of the matter can be left to us.



Specification

Model No

SNS-USB

Sensor

Omnivision/SONY/ON Semiconductor/GalxyCore...

Pixel

0.3MP 1MP 2MP 3MP 4MP 5MP 8MP 13MP 16MP

Compression format

MJPG / YUY2

Resolution & Frame rate

Optional

Shutter Type

Electronic rolling shutter/Global shutter

Focus type

Fixed focus/Auto focus

S/N ratio

TBDdB

Dynamic range

TBDdB

Sensitivity

Optional

Interface type

USB2.0/3.0

Adjustable parameter

Brightness/Contrast/Color saturation/Hue/Definition/
Gamma/White balance/Exposure

Lens FOV

Optional

Audio frequency

Support

Power supply

USB BUS POWER

Power consumption

DC 5V, 100mA

Main chip

DSP/SENSOR/FLASH

Auto Exposure Control (AEC)

Support

Auto White Balance (AEB)

Support

Auto Gain Control (AGC)

Support

Dimension

Customizable

Storage temperature

-20°C to 105°C

Operating temperature

0°C to 80°C

USB cable length

Default

Support OS

WinXP/Vista/Win7/Win8/Win10
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Android 4.0 or above with UVC



Auto Fixed Focus 16MP USB Camera Module Global Shutter For Face Recognition



Shenzhen Sinoseen Technology Co.,Ltd

China top 10 camera module manufacturer

We customize all kinds of USB/MIPI/DVP camera module as per your request





Camera Module Application Areas





Imaging and vision solutions                                               Integrated complex and customized technology
Machine vision                                                                     Intelligent Systems
Future Security                                                                     Optical technology solutions
Camera Module Customized solutions                                Internet of Things End-to-End Solution
Iris recognition technology                                                  Iris Solutions
Face recognition                                                                   VR High End Camera Solutions
Smart home solutions                                                          Intelligent hardware solutions
Professional camera Modules                                              Specially designed for small UAV
Airborne camera Modules                                                    UAV solutions
UAV Special Modules                                                           Drone solutions
Aerial filming solutions                                                         Optical Technology solutions
Mobile Phone Camera module                                             Camera solutions
Optronics Solutions                                                              Imaging Technology Solutions
Video technology solutions                                                 Optoelectonic research
Infrared Imagers for Industry                                               Embedded Systems solutions
