2MP GC2053 CMOS 1080P Mipi Camera Module Fixed Focus HD 30FPS

Brand Name : Sinoseen

Model Number : SNS21729-V1.0

Certification : RoHS

Place of Origin : Shenzhen,China

MOQ : 3

Price : negotiable

Payment Terms : T/T

Supply Ability : 500000 pieces/month

Delivery Time : 2-3weeks

Packaging Details : Tray+Anti-static bag in carton box

Type : 2MP camera module

Sensor : 1/2.9’GC2053 CMOS

Resolution : H1920*V1080

Dimensions : (customizable)

Pixel Size : 2.8um x2.8um

Focus Type : Fixed Focus

Interface : mipi

Feature : HD

Contact Now

2MP GC2053 CMOS 1080P Mipi Camera Module Fixed Focus HD 30FPS



2MP MIPI Camera Module

This is a compact camera system designed for high-definition imaging applications. It features a GC2053 CMOS image sensor capable of capturing images with a resolution of 2 megapixels. The camera module supports 1080P resolution, which is equivalent to a resolution of 1920 x 1080 pixels. This enables the module to capture high-quality, Full HD images or videos with crisp detail and clarity. The camera module is designed with a fixed-focus lens, that is, the focal length is set at a specific point and can be adjusted manually or automatically. These lenses are suitable for applications where the shooting distance is relatively constant, requiring a simple and cost-effective camera solution. The camera module supports a frame rate of 30 frames per second (FPS) at 1080P resolution. This frame rate provides smooth, real-time video capture, making it suitable for applications such as video conferencing, surveillance or live broadcasting. The 2MP GC2053 CMOS 1080P MIPI camera module with fixed focus and 30FPS capability provides a compact HD imaging solution. It is suitable for various applications requiring high-quality imaging and real-time video capture, such as mobile devices, video conferencing systems, or other applications requiring high-definition imaging.


Specification

Model No

SNS21729-V1.0

Sensor

1/2.9’GC2053 CMOS

Pixel

2 Mega Pixel

Most effective pixels

H1920*V1080

Pixel Size

2.8um x2.8um

Image Area

5808µm x 3288µm

Compression format

YUV2 / MJPG

Resolution

See above

Frame rate

See above

Shutter Type

Electronic rolling shutter

Focus type

Fixed focus

S/N ratio

TBDdB

Dynamic range

TBDdB

Sensitivity

3700 mV/lux-sec

Interface type

MIPI


Adjustable parameter

Brightness/Contrast/Color saturation/Hue/Definition/
Gamma/White balance/Exposure

Power supply requirement

AVDD28: 2.7~3.3V(Typ.2.8V)

DVDD18: 1.15~1.3V(Typ.1.2V)

IOVDD: 1.7~3.0V(Typ.1.8V)

Audio frequency

Optional

Power supply

USB BUS POWER

Power consumption

DC 5V, 200mA

Main chip

DSP/SENSOR/FLASH

Auto Exposure Control (AEC)

Support

Auto White Balance (AEB)

Support

Auto Gain Control (AGC)

Support

Storage temperature

0~60℃

Operating temperature

-20~80℃

USB cable length

Default

Support OS

WinXP/Vista/Win7/Win8/Win10
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Android 4.0 or above with UVC
